RTPFC Control Panel

50000.00 - 100000.00 INR/Unit

Get a Price/Quote

Product Details:

Rated Operation Voltage 440V
Rated Insulation Voltage 1100
Thickness 2 Millimeter (mm)
Product Type Other
Material Metal
Surface Finish Powder Coated
Rated Voltage 415 Volt (V)
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

RTPFC Control Panel Price And Quantity

Price Range 50000.00 - 100000.00 INR/Unit
Minimum Order Quantity 1 Unit

RTPFC Control Panel Product Specifications

Rated Voltage 415 Volt (V)
Rated Insulation Voltage 1100
Rated Operation Voltage 440V
Thickness 2 Millimeter (mm)
Material Metal
Surface Finish Powder Coated
Frequency (MHz) 50 Hz Hertz (HZ)
Product Type Other

RTPFC Control Panel Trade Information

Supply Ability 10 Unit Per Month
Delivery Time 15 Days
Main Domestic Market All India

Product Description

Real-Time Power Factor Correction (RTPFC) Panel comes with suitable detuned harmonic filter. We ensure that they compensate the changing Reactive Power and provide PF correction at an interval as low as 20 milliseconds i.e., faster than the speed of the blink of an eye.RTPFC Panels are most suitable for maintaining PF close to unity, reduction in kVA demand, reduction in electricity costs, enhancing capacity of Transformers, Switchgears, HT Cables are a few of the benefits accrued.
This state-of-the-art electronic switching device is primarily designed as a replacement of the electro-mechanically switched equipment. This system while clearly superior in terms of sheer speed of switching operations and comes with a price tag very much comparable with the conventional switching APFC systems.
This type of Power FactorCorrection is applicable in the industries like Steel Rolling Mills, Steel Melting Units, Forging, Welding, Press Shop,Induction Heating etc.
APFC panels with electromechanical contactors, have a well proven performance in installation where the load has periodic (non-dynamic) variations. However, today more and more industrial installations are having electronic equipment (PLC, Computers etc.) and very fast changing working cycles (automatic welding machines,robots etc.). Reactive Power Compensation with StaticThyristorSwitchesoffer the best answer to this requirement of the modern industry. Thyristors conducts and bring capacitors into circuitin virtually no time and at zero voltage across capacitors. The firing scheme grants a totally transient-free switching of capacitors, avoiding any problems related with transient over voltages. The reaction time (the time to switch ON or OFF a capacitor step) is usually as low as 20 milliseconds. This means that upto 50 operations per second are possible.
